NPH series of high-power batteries are designed for short-term power backup which needs high-rate discharge. We have designed sepcial plates to meet the sepcial requirement.
Model | Volt (V) |
Capacity (Ah ) |
Dimension (mm) | Approx. Weight (Kg) |
Terminal Type |
|||
---|---|---|---|---|---|---|---|---|
L | W | H | T.H. | |||||
NPH12-35W | 12 | 8 | 151 | 65 | 94 | 100 | 2.6 | F2 |
NPH12-55W | 12 | 12 | 152 | 99 | 96 | 102 | 3.8 | F2 |
NPH12-85W | 12 | 20 | 181 | 77 | 167 | 167 | 6.5 | T1 |
NPH12-115W | 12 | 28 | 165 | 126 | 174 | 174 | 8.8 | T3 |
NPH12-145W | 12 | 34 | 196 | 130 | 155 | 167 | 11.2 | T3 |
NPH12-170W | 12 | 42 | 198 | 166 | 174 | 174 | 14.0 | T3 |
NPH12-300W | 12 | 80 | 260 | 169 | 211 | 215 | 25.0 | T3 |
NPH12-370W | 12 | 95 | 307 | 169 | 211 | 215 | 31.0 | T3 |
NPH12-420W | 12 | 110 | 331 | 174 | 214 | 219 | 34.0 | T4 |
NPH12-470W | 12 | 135 | 407 | 174 | 210 | 233 | 39.0 | T5 |
NPH12-520W | 12 | 150 | 484 | 171 | 241 | 241 | 47.0 | T4 |
NPH12-680W | 12 | 170 | 532 | 206 | 216 | 221 | 59.0 | T5 |
NPH12-770W | 12 | 220 | 522 | 240 | 219 | 224 | 68.0 | T5 |
NPH12-800W | 12 | 230 | 520 | 269 | 204 | 209 | 70.0 | T5 |
NPH12-900W | 12 | 255 | 520 | 268 | 220 | 225 | 79.0 | T5 |
NPH6-720W | 6 | 180 | 260 | 180 | 247 | 251 | 31.0 | T5 |
